CHASSIS MODIFICATIONS
2-79
DAILY 4x4
Print 603.93.761 Base - May 2007
Electrical System: Modifications and Drawing-Off Power
Table 2.27
Connector on the vehicle IVECO code Interfacetobeused Part number Quantity
Male connector 98435341 Female connector 98435344 1
Half shell 1
Cable terminal 3
Gasket (rubber piece) 3
Cap 1
Connector pin-out:
Table 2.28
Pin Cable code Function Cable section (mm
2
) Max. current (A)
1 0000 Ground 1 10
2 3390 Vehicle right-side marker lights 1 10
3 3390 Vehicle left-side marker lights 1 10
As regards the vehicles on which the side dimmers are not co mpulsorily required, the respective conn ectors are in any case available.
In the event that the side dimmers need be installed, the vehicle shall be delivered to an IVECO service centre, in order to have
the body computer enabled.
