GENERAL SPECIFICATIONS
1-9
DAILY 4X4
Print 603.93.761 Base - May 2007
Dimensions and masses
Dimensions and masses
1.13 Dimensions and masses
1.13.1 General Specifications
The dimension s an d maximum permissible w eight on the axles are indicated on the bodybuilder layou t drawings, o n technical
specification sheets and, in greater details, on the official documentation issued by the Company. The kerb weights refer to vehicles
with standard equipment. Special equipment may involve con siderable modification to the weight and its distribution on the axles.
On our vehicles, lights and rear-view mirrors are designed for widths of up to 2350 mm.
Weighing the Chassis
As a result of production factors there could be at a ±5% variation in the published weights for models 35S and a ±3% for models
55S.
It is therefore, advisable to weigh the vehicle in the chassis cab condition before fitting the body and equipment and establish the
weight distribution on the axles.
Body conversions
The body building limits for each model are mainly defined by the following:
- weight distribution on the axles;
- width of the mirrors u sed;
- position of the rear under run-bar.
Greater values in compliance with the weights permitted on the axles may be authorized by IVECO after modifying such components
as the chassis, under run-bar, mirrors, etc.
