GENERAL SPECIFICATIONS
1-11
DAILY 4X4
Print 603.93.761 Base - May 2007
Dimensions and masses
In order to determine the payload on the axles, it must be uniformly distributed except when the shape of the loading surface itself
entails a different distribution of the load.
Regarding an y equipment, th e act ual position of the centre of gravity must be used.
When building bodies or containers, loading and unloading systems must be devised which preclude excessive variations in the
distribution of the load and/or excessive loads on the axles. Relevant instructions should also be given to the operator.
Uniform load distribution Uneven load distribution
Uniform load distribution Uneven load distribution
(beware of axle loads and minimum axle ratio)
102453
Figure 1.2
Figure 1.3
