Iveco DAILY 4x4 User Manual

2-78
CHASSIS MODIFICATIONS
D
AILY 4x4
Base - May 2007 Print 603.93.761
Electrical System: Modifications and Drawing-Off Power
2.16.8 Side Marker Lights
The local or EC standards in force in some countries lay down that the vehicles specially manufactured by the body builders
should be fitted with side marker lights o n the overall len gth of t he vehicle itself.
The Daily range vehicles are equipped with specific terminals to make the electric connection required to power the side marker
lights.
The external body builders shall take care to make the connections and install the lights on the respective added structures (boxes,
vans, etc.).
To ensure the electrical properties of the female connector contacts remain unchanged over time, leave the cap provided by IVECO
in place.
Below is an illustration of the position for the above terminal on the ch assis-cab.
!
It is not possible to draw current from side parking lights.
Figure 2.50
0000 Ground (pin 1)
3390 Right side (pin 2)
3390 Left side (pin 3)
102448
