71
7 Technical Data
Power supply 110 – 240 V~ / 50/60 Hz
Overvoltage category II
Safety class I (The device requires a ground connection via the mains
connection)
Contamination level 2
Acceptable voltage fluctuations ± 10 %
Max. power consumption 1650 W
Max. current consumption (informative) 16 A at 110–130 V~
9 A at 200–240 V~
Acceptable data for pumps of other manufacturers:
Max. output, final vacuum
250 W /max. leakage current 0.75 mA
< 50 mbar
Values and dimensions of electrical fuses
Heating circuit:
T15AH 250 V
6.3 x 32 mm
Vacuum pump:
T5AH 250 V
5 x 20 mm
Dimensions of the closed furnace Depth: 494 mm
Width: 280 mm / 415 mm (without/with cooling tray)
Height: 450 mm / 573 mm (closed/open)
Usable size of the firing chamber: Diameter: 55 mm
Height: 40 mm
Max. firing temperature 1560°C (2192°F)
Weight 28.5 kg
7.1 Applied standards
The furnace was tested in accordance with the following standards:
Device safety – EN 61010-1:2010/A1:2019
– UL 61010-1:2012/R:2018-11
– CAN/CSA-C22.2 No. 61010-1:2012/A1:2018-11
– IEC 61010-1:2010+AMD1:2016
– EN 61010-2-010:2020
– UL 61010-2-010:2019
– CAN/CSA-C22.2 No. 61010-2-010:2019
– IEC 61010-2-010:2019
Electromagnetic compatibility – EN 61326-1:2013, group 1, class B
– IEC 61326-1:2012, group 1, class B
– EN 61000-3-2:2019
– IEC 61000-3-2:2018
– EN 61000-3-3:2013+A1:2019
– IEC 61000-3-3:2013+AMD1:2017
– USA (FCC): 47 CFR, Part 15, Subpart B – Unintentional
radiator class B
– Canada (IC): ICES-003 – Unintentional radiator class B
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
This device complies with Part 15 of the FCC Rules and with Industry Canada’s licence-exempt RSSs. Operation is subject to
the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation.
