Ivy Biomedical Systems 101R User Manual

MONITOR DESCRIPTION
Trigger Output
Phase Delay fromElectrode
Leads to Trigger Output: < 3 ms
R to R Trigger Accuracy: ±200 µs typical @ 1 mV input
Sensitivity and Threshold
Adjustment: Fully Automatic
Optional Trigger Delay: User adjustable from 0 to 700 ms in 5 ms increments.
Environmental
Operating Temperature
Range: 5°C to 45°C
Storage Temperature
Range: -25°C to 60°C
Relative Humidity: 0-90% non-condensing
Power Requirements
Voltage Input: 100, 120, 220, 230, V ~, 50/60 Hz; +10% - 15%
(to change mains operating voltage see text on Monitor Setup).
Maximum ac Power
Consumption: 85 VA
Safety
Unit meets or exceeds the specifications for the AAMI Cardiac Monitor Standard. Units meet UL544,
CSA, and CE-MDD 93/42/ECC requirements. ISO-9001 Approval # 98-1044.
Model 101R/NR Service Manual
6
