TESTING AND TROUBLESHOOTING
Block Diagram
AUDIO
CIRCUITS SPEAKER
U13,Q19,Q20
FRONT
PANEL
RAMP HORIZONTAL
GENERATOR DEFLECTION
U16A U7
HORIZONTAL
CORRECTION
U17
HIGH VOLTAGE
POWER SUPPLY
AND VIDEO CRT
AMPLIFIER
CPU AND DIGITAL
CIRCUITS D/A
CONVERTOR
U29
MULTIPLEXER VERTICAL
Q15, Q16 DEFLECTION
U6
RASTER
GENERATOR
U8B
A/D
CONVERTOR
U21
TRIGGER
PEAK CIRCUITRY TRIGGER
DETECTOR U18A, U12 OUTPUT
U23B
ISOLATED
TEST
CIRCUIT
U44
PROTECTION LEAD NOTCH
CIRCUITS SELECT FILTER
U45 U26C
ECG
INPUT
SHIELD
DRIVE
ECG X1000
BUFFER
MOTHER BOARD
Model 101R/NR Service Manual 39
