TESTING AND TROUBLESHOOTING
Troubleshooting Table
General
No Apparent Power 1. Power source
2. Main fuse
3. Internal fuses
No Display
(Check Key Signals)
1. CRT
2. HVPS board
3. Mother Board
CRT
Bad Horizontal or Vertical
1. Mother Board
Test OK 1. Patient Cable
2. Connector-Front Panel to
Mother Board
3. Input Amplifiers on
Mother Board
ECG
Test Not OK
1. Mother Board
No Audio At All 1. Mother Board
2. Connection to Speaker
3. Speaker
No Alarm Audio 1. Alarm On/Off Setting
2. Mother Board
Audio
No ECG Audio 1. Rear Panel switch setting
2. Mother Board
38 Model 101R/NR Service Manual
