RECORDER OPERATION
Model 101R/NR Service Manual 21
Timed TIMED mode starts by pressing PRINT and prints for 30 seconds.
Delay Delay mode plots the 19 seconds before and 12 seconds after the occurrence of an alarm condition or if
print button is pushed.
To set the Time and Date
Use the following procedure to set the date and time. The date and time are indicated in the lower right corner of the
display.
1. Press the MENU key once. The main menu appears.
2. Press the programmable key (TRIG. MARK) once to select RECORDER.
3. Press the programmable key (TRIG. MARK) once to select SET CLOCK.
N
E
X
T
11:20 AM
25 SEPT 98
×
Ø
ENTER
4. Press the programmable key (SPEED 25/50mm/s) to place the flashing cursor under the hour, minutes,
date, month or year.
5. Press the programmable key (FREEZE) to increase
× what the cursor is under or press the
programmable key (ALARM RESET) to lower Ø what the cursor is under.
6. After changing the settings press the programmable key (TRIG MARK) to ENTER the settings.
