18
One-way keyfobs
One-way keyfobs send a signal every time a button is pressed without receiving feedback from the control
panel. Sending a signal is confirmed only by a short flash of the red LED and alternatively with a beep.
The button functions are differentiated by lock icons. The closed lock icon sets programmed sections; the
opened lock icon unsets them. The buttons with symbols of full and empty circles can control another section
or one status PG output (e.g. to turn the lights on and off) or two PG outputs (e.g. a garage door and door lock).
A low battery is indicated by a red LED and acoustically (3 fast beeps).
2.4 OPERATING THE SYSTEM USING
A COMPUTER AND A USB CABLE (J-LINK)
The JABLOTRON 100 can be operated locally or remotely (see chapter 2.9) using
a computer and installed J-Link software (Windows XP and higher), which can be used
for user management (add/remove users, change their level of authorization, phone
numbers, codes, card/tags, etc.).
The J-link software is available for local connection with a control panel.
It is located on the system’s security drive (FLEXI_CFG/j-link), which will appear after
the control panel is connected to a PC via USB.
It is possible to set / unset the system using icons on the lower bar of the
program or with the “Status” buttons in the “Section” tab. If a keypad with at least one
controllable segment is used with the system, then it is possible to set/unset
the system in the J-Link software using an on-screen virtual keypad (click on “Keypad“
in the main menu).
WARNING: When the system is controlled via PC, it doesn’t check for triggered devices while setting.
This may lead to setting with a triggered device. Be careful when you control the system this way!
2.5 OPERATING THE SYSTEM USING
THE VOICE MENU
The system can be controlled from a mobile phone or land line through a simple voice
menu, which guides the user through a series of options in the preconfigured language.
To access the voice menu, you just dial the alarm system’s phone number.
Access to the voice menu can be enabled either to all telephone numbers
without restrictions or alternatively only to authorized phone numbers stored
in the control panel. Depending on the configuration, authorization by entering
a valid code on a phone keypad may be required. When the user enters the menu,
the system will give an update of the current status of all sections assigned to the user.
The caller then can control these sections, either individually or collectively,
using phone keypad and available menu options.
The system default is set up to answer incoming calls after three rings (approximately
15 seconds).
2.6 OPERATING THE SYSTEM VIA
THE MyJABLOTRON WEB INTERFACE
The JABLOTRON 100 system can be easily and conveniently operated using your computer via the internet
and the MyJABLOTRON web interface, which is accessible from www.myjablotron.com. For more information
about this web interface please see the chapter 6.
2. OPERATING THE JABLOTRON 100 SYSTEM
