6
2. OPERATING THE JABLOTRON 100 SYSTEM
Continuous yellow
PARTIALLY SET
Access module
CARD READER / KEYPAD
Continuous red
SET / ON
Flashes red
ALARM /
ALARM MEMORY
Ways of operating the JABLOTRON 100
On-site:
a System keypad
a System keyfob
a Computer using a USB cable and the J-Link software
Remotely:
a Telephone using the voice menu
a Computer, via the MyJABLOTRON web interface
a MyJABLOTRON smartphone application
a Mobile – via SMS
a Computer, via the internet using the J-Link software
a Dialling-in from an authorized telephone number
(only for operating programmable outputs)
Flashes red
ALARM / ALARM MEMORY
Continuous green
EVERYTHING OK
Flashes green
CONTROL
Continuous yellow
FAULT
Flashes yellow
UNSUCCESSFUL
SETTING
Continuous green
UNSET / OFF
Flashes green
ENTRY DELAY
2.2 USING THE SYSTEM KEYPAD
2.2.1 USING THE SEGMENT KEYPADS
JABLOTRON 100 system may be controlled by a variety of access modules which let you not just control
but also display statuses of individual segments. The system can be operated directly (setting or unsetting
the system and other automation functions) using two-button segments on the keypad. The segment buttons are
clearly labelled and coloured (using traffic light logic) so that each segment’s status is distinctly indicated.
A segment can also be used to indicate a status (e.g. opened garage door) or to control various automated
devices (for example heating or window shutters). The maximum number of segments is 20 for one access
module. A segment can also be set up to call for help in an emergency (medical or panic alarm).
