24
JABLOTRON ALARMS a.s. hereby declares that these control panels JA-101K, JA-101K(-LAN)(3G) a JA-106K
(-3G) meet the basic requirements and other relevant provisions of the Directive no. 2014/53/EU, 2014/35/EU,
2014/30/EU and 2011/65/EU. You will find the original Declaration of Conformity at www.jablotron.com, section
Downloads.
Note: Although this product does not contain any harmful materials we suggest you return the product to the dealer
or directly to the producer after use. For more detailed information visit www.jablotron.com.
8. TECHNICAL SPECIFICATIONS
Parametr JA-101K (-LAN) (-LAN3G) JA-106K (-3G)
Control panel power
supply
~ 230 V/50 Hz, max. 0.1 A
with T200 mA fuse
~ 110 V to 120 V/60 Hz, max. 0.2 A,
with T400 mA fuse protection class II
~ 230 V / 50 Hz, max. 0.2 A,
with T400 mA fuse protection class II
Back-up battery 12 V; 2.6 Ah 12 V; 7 to 18 Ah
Maximum battery
charging time
72 h 72 h
BUS voltage (red-black) 12.0 to 13.8 V 12.0 to 13.8 V
Max. continuous
consumption from
the control panel
400 mA permanently
(1000 mA for 5 minutes)
1200 mA permanently, valid for each BUS
output
(2000 mA for 10 minutes)
Max. continuous
consumption
for backing up 12 hours
JA-101K - battery 2,6 Ah JA-106K – battery 18 Ah
Without GSM
communicator
LAN – OFF – 123 mA
LAN – ON – 78 mA
Without GSM
communicator
LAN – OFF – 1150 mA
LAN – ON – 1105 mA
With GSM
communicator
LAN – OFF – 103 mA
LAN – ON – 58 mA
With GSM
communicator
LAN – OFF – 1130 mA
LAN – ON – 1085 mA
Max. continuous
consumption
for backing up 24 hours
Without GSM
communicator
LAN – OFF – 37 mA
LAN – ON – Not possible
Without GSM
communicator
LAN – OFF – 550 mA
LAN – ON – 505 mA
With GSM
communicator
LAN – OFF – 17 mA
LAN – ON – Not possible
With GSM
communicator
LAN – OFF – 530 mA
LAN – ON – 485 mA
Max. number
of devices
50 120
LAN communicator Ethernet interface (LAN versions only) Ethernet interface
Dimensions (mm) 258 x 214 x 77 357 x 297 x 105
Weight 1250 g 2500 g
Reaction to invalid code
entry
Alarm after 10 wrong code entries
Event history approx. 7 million latest events, incl. date and time
Power supply unit type A (EN 50131-6)
T 031 note: In case of a main power failure is the system backed up for 24 hours and at
the same time is a failure report sent to the ARC.
GSM communicator 850 / 900 / 1800 / 1900 MHz
3G GSM communicator 2100 MHz
Environmental class class II, indoor general according to EN 50131-1
Operational temperature
range
-10 °C to +40 °C, relative humidity 75 %
Classification Security grade 2 according to EN 50131-1, EN 50131-3, EN 50131-6, EN50131-10,
EN 50131-5-3, EN 50136-1, EN 50136-2
Operating frequency
(with the JA-11xR module)
868.1 MHz
Radio emissions ETSI EN 300 220-2 (module R), ETSI EN 301 419-1, ETSI EN 301 511 (GSM)
EMC EN 50130-4 ed. 2, EN 55022 ed. 3, ETSI EN 301 489-7
Safety EN 60950-1
Operational conditions ERC REC 70-03, ERC DEC (98) 20
Certification body TREZOR TEST: (JA-101K, JA-101K-LAN, JA-106K),
ANPI: INCERT T014(A) (JA-101K, JA-106K)
Caller’s identification ETSI EN 300 089
