16
07610-004-33-05-E
RackStar 66 - 70º
RackStar 66 - 40º
RackStar 66 - ER
SPECIFICATIONS
ELECTRICAL REQUIREMENTS
i
Local codes may require more stringent protection than what is displayed here and on the data plate. Always verify with your electrical service contractor that your circuit
protection is adequate and meets all applicable national and local codes. Numbers in this manual are for reference and may change without notice. If using a third-party
external booster, consult booster manufacturer for booster information. With dual-point connection (standard), Booster Heater has its own connection. Imbalanced wild
leg goes to L3. Also see the Motor Rotation section.
5
5
RackStar 66 Dual-point Connection (Standard)
Volts Phase Freq
PW
Motor
Wash
Motor
Drive
Motor
Wash
Heater
Total
Load
MCA MOP
208 3 60 Hz 6.2 A 9.2 A 1.1 A 41.6 A 58.1 A 60.4 A 65 A
230 3 60 Hz 6.2 A 8.6 A 1.1 A 34.6 A 50.5 A 52.6 A 60 A
460 3 60 Hz 3.1 A 4.3 A 0.7 A 17.3 A 25.4 A 26.5 A 30 A
Booster
Heater
MCA MOP
47.9 A 49.2 A 50 A
43.3 A 44.6 A 45 A
21.7 A 23.0 A 25 A
Booster
Heater
MCA MOP
33.3 A 34.6 A 35 A
28.9 A 30.2 A 35 A
14.4 A 15.7 A 20 A
Booster
Heater
MCA MOP
74.9 A 76.2 A 80 A
65.0 A 66.3 A 70 A
32.5 A 33.8 A 35 A
Volts Phase Freq
PW
Motor
Wash
Motor
Drive
Motor
Wash
Heater
Total
Load
MCA MOP
208 3 60 Hz 6.2 A 9.2 A 1.1 A 41.6 A 58.1 A 60.4 A 65 A
230 3 60 Hz 6.2 A 8.6 A 1.1 A 34.6 A 50.5 A 52.6 A 60 A
460 3 60 Hz 3.1 A 4.3 A 0.7 A 17.3 A 25.4 A 26.5 A 30 A
Volts Phase Freq
PW
Motor
Wash
Motor
Drive
Motor
Wash
Heater
Total
Load
MCA MOP
208 3 60 Hz 6.2 A 9.2 A 1.1 A 41.6 A 58.1 A 60.4 A 65 A
230 3 60 Hz 6.2 A 8.6 A 1.1 A 34.6 A 50.5 A 52.6 A 60 A
460 3 60 Hz 3.1 A 4.3 A 0.7 A 17.3 A 25.4 A 26.5 A 30 A
