Jackson RackStar 44 - Miscellaneous Electrical Components

07610-004-33-05-E
40
PARTS
MISCELLANEOUS ELECTRICAL COMPONENTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Actuator Switch 05930-111-68-44
2 1 Float Switch 06680-121-70-71
3 1 Float Switch Cover 05700-004-71-80
4 1 Probe Fitting, Brass 05310-924-02-05
5 1 Thermistor Probe 06685-004-34-58
6 6 Fuse, 200 mA Slow-acting 05999-004-44-33
7 2 Fuse, 1 A Fast-acting 05999-004-47-87
1
2
3
4
5
Parts are not shown to scale with relation to each other.
6
7
