Jackson RackStar 44 - Electrical Requirements

14
07610-004-33-05-E
All electrical ratings provided in this manual are for reference only. Always refer to the
machine data plate to get the exact electrical information for this machine. All electrical
work performed on machines should be done in accordance with applicable
local, state, territorial, and national codes. Work should only be performed by qualied
electricians and authorized service agents.
All electrical wiring used in the dishmachine must be rated, at a minimum, for
212 °F (100 °C), and only copper conductors must be used.
Where applicable, heating element amperage draws have been adjusted for the assumed
input voltage. The manufacturer assumes incoming voltages will be either 208, 230, or 460
Volts. Some of the heating elements used in our machines are actually rated for other
voltages, such as 240 or 480 Volts. Always verify the amperage draw of the machine in
operation when sizing circuit protection.
If the machine is equipped with a booster heater, note the heater has its own electrical
connection and therefore requires a separate service (single-point connection is available
as an option on three-phase machines only). Amperage loads for motors and heaters are
listed on the machine data plate for the installation/service technician.
The electrical congurations of the machines are as follows:
Available Electrical Characteristics:
• 208 V, 60 Hz, Three-phase
• 230 V, 60 Hz, Three-phase
• 460 V, 60 Hz, Three-phase
• 600 V, 60 Hz, Three-phase
Available Wash Tank Heaters:
• 15 kW
Available Booster Tank Heaters:
• None (standard)
• 12 kW (40 °F rise in temperature)
• 18 kW* (70 °F rise in temperature)
• 27 kW (ER unit only)
i
SPECIFICATIONS
ELECTRICAL REQUIREMENTS
NOTICE
*On 208/60/3 machines, the booster heater is rated at 17.2 kW.
ELECTRICAL
REQUIREMENTS
Booster heaters require
a separate electrical
connection unless the
single-point option is
selected.
i
