47
07610-004-33-05-E
PARTS
ENERGY RECOVERY PLUMBING
ITEM QTY DESCRIPTION PART NUMBER
1 1 Manifold, Tank Fill 05700-004-38-64
2 3 Elbow, 90-degree 1/2" Street Brass 04730-206-08-00
3 1 Solenoid Valve, 1/2" 04810-003-71-55
4 2 Nipple, 1/2" Close Brass 04730-207-15-00
5 1 Tee, 1/2" Brass 04730-211-27-00
6 1 Piping Manifold, Single-point Tubing 05700-004-48-43
7 1 Vacuum Breaker, 1/2" Brass 04820-003-06-13
8 1 Y-Strainer, 1/2" 04730-217-01-10
9 1 Plug, 1/2" Brass Pipe 04730-209-03-00
Complete ER Fill Plumbing Assembly, L-R*
05700-004-41-53
Complete ER Fill Plumbing Assembly, R-L*
05700-004-41-54
*For areas with low ground-water temperature, a thermostatic mixing valve should be used:
Complete ER Fill Plumbing Assembly with Mixing Valve, L-R
05700-004-42-94
Complete ER Fill Plumbing Assembly with Mixing Valve, R-L
05700-004-42-95
