07610-004-33-05-E
42
PARTS
VOLTAGE PHASE KW PART NUMBER CONTACTOR
208 1 15 04540-121-68-45 05945-111-68-38
230 1 15 04540-121-68-46 05945-111-68-38
208 3 15 04540-121-68-45 05945-002-24-70
230 3 15 04540-121-68-46 05945-002-24-70
460 3 15 04540-121-68-47 05945-002-24-70
600 3 15 04540-002-39-93 05945-002-24-70
When replacing wash heaters, it is highly recommended to change the gasket as well. Once installed, gaskets
become compressed and are subject to extreme temperature changes. Replacing the gasket with the heater
might prevent future leaks.
The nuts used to secure the heater to the casting should be torqued to 16 in-lbs. After tightening, the machine
should be allowed to heat up and operate normally for approximately 30 minutes. Secure power to the machine
and check the nuts once more to verify they are torqued to 16 in-lbs.
WASH HEATERS
