07610-004-33-05-E
64
PARTS
MOTOR OVERLOADS
WASH MOTOR
VOLTAGE
PART NUMBER GE PART NUMBER
208 05945-004-35-45 RT1N
230 05945-004-35-45 RT1N
460 05945-111-81-33 RT1L
600 05945-111-68-41 RT1K
DRIVE MOTOR
VOLTAGE
PART NUMBER GE PART NUMBER
208 05945-111-68-39 RT1G
230 05945-111-68-39 RT1G
460 05945-002-71-09 RTN1F
600 05945-111-68-39 RT1G
Pre-wash MOTOR
VOLTAGE
PART NUMBER GE PART NUMBER
208 05945-111-68-40 RT1M
230 05945-111-68-40 RT1M
460 05945-111-68-41 RT1K
600 05945-111-68-41 RT1K
WASH MOTORS: Overloads are specied for 3-phase units only.
For GE brand MT03* series overloads, the process for setting is as follows:
Determine the Full Load Amps (FLA) for the wash motor.
Set the overload at the closest setting without going over for the FLA of the motor.
The overload already compensates for the FLA and will have a setpoint that is 125% of the FLA. (Example: Wash motor
is rated at 10.0 FLA on the data plate. The replacement MT03* overload will be set at 10.0. It will trip at 12.5 Amps.)
Blue selector switch should be
set to H for manual reset.
DRIVE MOTORS: Overloads are specied for 3-phase units only.
For GE brand MT03* series overloads, the process for setting is as follows:
Determine the FLA for the drive motor.
Set the overload at the closest setting without going over for the FLA of the motor.
The overload already compensates for the FLA and will have a setpoint that is 125% of the FLA. (Example: Drive motor
is rated at 1.0 FLA on the data plate. The replacement MT03* overload will be set at 1.0. It will trip at 1.25 Amps.)
Blue selector switch should be
set to H for manual reset.
PRE-WASH MOTORS (66 ONLY): Overloads are specied for 3-phase units only.
For GE brand MT03* series overloads, the process for setting is as follows:
Determine the FLA for the Pre-wash motor.
Set the overload at the closest setting without going over for the FLA of the motor.
The overload already compensates for the FLA and will have a setpoint that is 125% of the FLA. (Example: Pre-wash
motor is rated at 6.0 FLA on the data plate. The replacement MT03* overload will be set at 6.0. It will trip at 7.5 Amps.)
Blue selector switch should be
set to H for manual reset.
Connections should be tightened to 7 in-lbs.
NOTICE
