SPECIFICATIONS
ELECTRICAL REQUIREMENTS
i
Local codes may require more stringent protection than what is displayed here and on the data plate. Always verify with your electrical service contractor that your circuit
protection is adequate and meets all applicable national and local codes. Numbers in this manual are for reference and may change without notice. With single-point
connection (option), Booster Heater shares a connection with machine. Imbalanced wild leg goes to L3. Also see the Motor Rotation section.
5
5
RackStar 66 Single-point Connection (Option)
Volts Phase Freq
PW
Motor
Wash
Motor
Drive
Motor
Wash
Heater
Booster
Heater
Total Load MCA MOP
208 3 60 Hz 6.2 A 9.2 A 1.1 A 41.6 A 47.9 A 106.0 A 108.3 A 115 A
230 3 60 Hz 6.2 A 8.6 A 1.1 A 34.6 A 43.3 A 93.8 A 95.9 A 100 A
460 3 60 Hz 3.1 A 4.3 A 0.7 A 17.3 A 21.7 A 47.1 A 48.2 A 50 A
Volts Phase Freq
PW
Motor
Wash
Motor
Drive
Motor
Wash
Heater
Booster
Heater
Total Load MCA MOP
208 3 60 Hz 6.2 A 9.2 A 1.1 A 41.6 A 33.3 A 91.4 A 93.7 A 100 A
230 3 60 Hz 6.2 A 8.6 A 1.1 A 34.6 A 28.9 A 79.4 A 81.5 A 90 A
460 3 60 Hz 3.1 A 4.3 A 0.7 A 17.3 A 14.4 A 39.8 A 40.9 A 45 A
Volts Phase Freq
PW
Motor
Wash
Motor
Drive
Motor
Wash
Heater
Booster
Heater
Total Load MCA MOP
208 3 60 Hz 6.2 A 9.2 A 1.1 A 41.6 A 74.9 A 133.0 A 135.3 A 140 A
230 3 60 Hz 6.2 A 8.6 A 1.1 A 34.6 A 65.0 A 115.5 A 117.6 A 125 A
460 3 60 Hz 3.1 A 4.3 A 0.7 A 17.3 A 32.5 A 57.9 A 59.0 A 60 A
Volts Phase Freq
PW
Motor
Wash
Motor
Drive
Motor
Wash
Heater
Booster
Heater
Total Load MCA MOP
208 3 60 Hz 6.2 A 9.2 A 1.1 A 41.6 A N/A 58.1 A 60.4 A 65 A
230 3 60 Hz 6.2 A 8.6 A 1.1 A 34.6 A N/A 50.5 A 52.6 A 60 A
460 3 60 Hz 3.1 A 4.3 A 0.7 A 17.3 A N/A 25.4 A 26.5 A 30 A
Volts Phase Freq
PW
Motor
Wash
Motor
Drive
Motor
Wash
Heater
Booster
Heater
Total Load MCA MOP
208 3 60 Hz 6.2 A 9.2 A 1.1 A N/A N/A 16.5 A 18.8 A 25 A
230 3 60 Hz 6.2 A 8.6 A 1.1 A N/A N/A 15.9 A 18.1 A 25 A
460 3 60 Hz 3.1 A 4.3 A 0.7 A N/A N/A 8.1 A 9.2 A 15 A
