Jackson RackStar 44 - Page 59

51
07610-004-33-05-E
ITEM QTY DESCRIPTION PART NUMBER
1 1 Pump & Motor Assembly See Table Below
2 1 Gasket, Pump Suction 05330-003-75-87
3 1 Gasket, Pump Discharge 05330-003-75-88
4 2 Hose Clamp, Range 2 9/16" to 3 1/2" 04730-003-15-40
5 1 Hose, Wash Pump Discharge 05700-003-77-62
6 1
Lower Wash Manifold, L-R
Lower Wash Manifold, R-L
05700-004-27-39
05700-004-30-27
7 1 Casting, Wash Manifold 09515-003-71-50
8 1 Tube, Manifold Riser 05700-003-72-37
9 1 Upper Wash Manifold 05700-003-73-66
10 1 Wash Arm, Top-right 05700-003-75-79
11 1 Wash Arm, Top-left 05700-003-75-80
12 12 Cap, Threaded 04730-603-12-00
13 3 O-ring, Silicone, 0.103 Dia., 2 1/2" x 2 11/16" OD 05330-003-73-71
14 4 O-ring, Silicone, 0.139 Dia., 2 1/4" ID x 2 1/2" OD 05330-003-73-72
15 1 Wash Arm, Bottom-right 05700-004-27-43
16 1 Wash Arm, Bottom-left 05700-004-27-42
PUMP & MOTOR ASSEMBLY PART NUMBER
Wash Pump, 3 HP, 208 V, 60 Hz, 3-Phase 06105-003-76-11
Wash Pump, 3 HP, 230 V, 60 Hz, 3-Phase 06105-003-76-11
Wash Pump, 3 HP, 460 V, 60 Hz, 3-Phase 06105-003-76-11
Wash Pump, 3 HP, 600 V, 60 Hz, 3-Phase 06105-004-53-85
PARTS
WASH SYSTEM
