Jackson RackStar 44 - Page 61

53
07610-004-33-05-E
ITEM QTY DESCRIPTION PART NUMBER
1 1 Gasket, Pump Suction 05330-003-75-87
2 2 Hose Clamp 04730-003-15-40
3 1 Hose, Wash Pump Discharge 05700-003-77-62
4 1 Manifold, Pre-wash System 05700-004-31-60
5 3 O-ring, Silicone, 0.103 Dia., 2 1/2" x 2 11/16" OD 05330-003-73-71
6 1 Tube, Manifold Riser 05700-003-81-53
7 2 Casting, Pre-wash Manifold 09515-003-77-22
8 2 O-ring, Silicone, 0.139 Dia., 2 1/4" ID x 2 1/2" OD 05330-003-73-72
9 1 Pre-wash Arm 05700-003-75-79
10 4 Cap, Threaded 04730-603-12-00
11 1 Pre-wash Arm, Lower 05700-003-80-96
12 1 Gasket, Pump Discharge 05330-003-75-88
13 1 Pre-wash Motor See Table Below
PUMP & MOTOR ASSEMBLY PART NUMBER
Pre-wash Pump, 2HP, 208 V, 60 Hz, 3-Phase 06105-003-76-12
Pre-wash Pump, 2HP, 230 V, 60 Hz, 3-Phase 06105-003-76-12
Pre-wash Pump, 2HP, 460 V, 60 Hz, 3-Phase 06105-003-76-12
Pre-wash Pump, 2HP, 600 V, 60 Hz, 3-Phase 06105-004-53-84
PARTS
PRE-WASH SYSTEM
