Jackson RackStar 44 - Page 67

59
07610-004-33-05-E
ITEM QTY DESCRIPTION PART NUMBER
1 1 Front Rack Rail 05700-004-26-87
2 3 Paddle Switch 05700-004-26-89
3 4 Screw, 1/4-20 x 5/8" Hex 05305-274-24-00
4 7 Glide Block 05700-004-11-75
5 1 Rear Rack Rail 05700-004-22-95
6 2 Screw, 1/4-20 x 7/8" Hex 05305-274-05-00
7 1 Rack Rail, Pre-wash 05700-004-47-04
8 17 Screw, 1/4-20 x 1" Hex 05305-274-27-00
9 1
Paddle Switch, Pre-wash, L-R
Paddle Switch, Pre-wash, R-L
05700-004-34-03
05700-004-34-06
10 9 Spacer, Rack Guide 05700-011-71-44
11 9 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
Front Rack Rail
Complete Assembly
(Everything below.)
05700-004-26-88
Rear Rack Rail
Complete Assembly
(Everything below.)
05700-004-26-86
Pre-wash Front Rack Rail
Complete Assembly
(Everything below.)
Left-to-Right Right-to-Left
05700-004-47-07 05700-004-47-13
Pre-wash Rear Rack Rail
Complete Assembly
(Everything below.)
05700-004-47-06
PARTS
RACK RAILS
To order complete assemblies:
