67
07610-004-33-05-E
ITEM QTY DESCRIPTION PART NUMBER
1 1
Tub Weldment, 23" Side-loader L-R
Tub Weldment, 23" Side-loader R-L
Tub Weldment, 30" Side-loader L-R
Tub Weldment, 30" Side-loader R-L
05700-004-37-44
05700-004-38-03
05700-003-88-46
05700-003-88-39
2 2 Support Leg 05700-021-87-59
3 2 Adjustable Foot 05340-108-01-03
4 39 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
5 2 Leg Socket 05700-002-56-14
6 1
Track, Side-loader L-R 05700-003-90-00
Track, Side-loader R-L 05700-003-89-95
7 1 Actuator Switch Assembly 05700-004-53-51
8 1 Gutter, Pawl Bar 05700-021-66-86
9 1 Guide Block Bottom-slotted 05700-011-69-50
10 1 Guide Block Top-slotted 05700-011-69-49
11 1 Gasket, Drive Gutter 05330-011-68-55
12 1 Strainer 05700-021-85-10
13 1 Drain Assembly, Side-loader 05700-004-38-17
14 1 Bracket, Loader Pawl Bar Support 05700-003-87-39
15 16 Washer, 1/4" 05311-174-01-00
16 2 Roller 05700-011-68-16
17 2 Roller Shaft 05700-011-68-14
18 2 Screw, 1/4-20 x 1 3/4" Hex 05305-274-10-00
19 4 Bolt, 1/4-20 x 1/2" 05305-274-02-00
20 1 Cover, Side-loader Switch 05700-003-87-41
21 1 Bracket, Limit Switch 05700-021-71-18
22 1 Conduit and Wiring, Side-loader 05700-004-38-53
23 1 Magnetic Reed Switch 05930-111-68-44
PARTS
SIDE-LOADERS
