75
07610-004-33-05-E
Complete Energy Recovery System Assembly
L-R - 05700-004-39-68
R-L - 05700-004-40-13
L-R HH - 05700-004-68-92
R-L HH - 05700-004-69-04
PARTS
ENERGY RECOVERY SYSTEM
ITEM QTY DESCRIPTION PART NUMBER
1
1
Vent Cowl, L-R
Vent Cowl, L-R HH
05700-004-36-36
05700-004-68-91
1
Vent Cowl, R-L
Vent Cowl, R-L HH
05700-004-40-16
05700-004-69-03
2 1 Mounting Plate 05700-004-36-32
3 20 Washer, 1/4-20 05311-174-01-00
4 24 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
5 1 Coil, Heat Exchanger 04420-004-40-73
6 1 Side Cover, Left 05700-004-41-17
7 1 Side Cover, Right 05700-004-41-18
8 1 Top Coil Support 05700-004-40-40
9 1 Air Bafe 05700-004-36-66
10 2 Curtain Hook 05700-003-17-98
11 1 Curtain Rod 05700-003-77-52
12 1 Coil Housing Top 05700-004-36-73
13 1 Collar, Vent Scoop 05700-004-36-71
14 1
Curtain, 20 1/2" x 19"
Curtain, HH 20 1/2" x 29 3/4"
08415-002-14-41
08415-004-49-64
15 1 Bafe, Vent Cowl 05700-002-11-47
16 5 Screw, 1/4-20 x 5/8” Hex 05305-274-24-00
17 10 Screw, 10-32 x 1/2" 05305-011-39-36
18 1 Drip Tray 05700-004-42-09
19 3 Locknut, 1/4-20 Low Prole with Nylon Insert 05310-374-02-00
20 2 Bushing, 3/4" to 1/2" Hex, Brass 04730-002-56-27
21 1 Plumbing, Temperature Gauge, Coil 05700-004-42-88
22 1 Check Valve, 1/2" 04730-004-79-79
DESCRIPTION PART NUMBER
Hose, Inlet (Blue) 05700-004-42-29
Hose, Coil Outlet (Red) 05700-004-42-30
Hose, Booster Outlet (Red) 05700-004-42-31
Hose, 1/2" x 23" (Blue) 05700-004-42-32
Hose, 1/2" x 47" (Red) 05700-004-42-33
Hose, 1/2" x 38" (Red) 05700-004-42-34
Hose, 1/2" x 5" (Blue) 05700-004-42-89
Hoses for Energy Recovery System (Not Shown)
