Jackson TempStar Series User Manual

07610-002-23-32-AC
2
4 in [102 mm]
25
1
4
in
[641 mm]
4 in
C
B
25
1
4
in [641mm]
3
7
8
in
[97 mm]
1 in [25 mm]
B
C
34 in
[864mm]
11
3
4
in [299mm]
A
68
1
2
in
[1740 mm
]
76
3
8
in
[1941 mm]
25
1
4
in
[641 mm]
73
3
4
in
[1874 mm]
27 in
[686mm]
86
3
4
in
[2203 mm]
A
73
[1854mm]
17 in [432 mm]
C
B
28
5
8
in [727mm]
25 in [635mm]
[102mm]
1
4
15 in [387mm]
in
LEGEND
A - Drain 1 1/2" NPT
B - Water Inlet 3/4" NPT
C - Electrical Connection
All dimensions from the oor can be
increased 2" using the machine's
adjustable feet.
MACHINE DIMENSIONS
SPECIFICATIONS

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
