11
07610-002-23-32-AC
WATER SUPPLY
CONNECTION:
WATER HARDNESS
GREATER THAN
5 GPG
WATER SUPPLY
CONNECTION:
WATER HARDNESS
OF 5 GPG OR LESS
PRESSURE
REGULATOR
SHOCK ABSORBER
CONNECTING THE
DRAIN LINE
If water hardness tests at greater than 5 GPG, install the HTS-11 into the water
line before the dishmachine’s incoming water connection point using copper pipe.
Observe proper inlet/outlet water directions. A water shut-off valve should be
installed to allow access for service. Plumb from the HTS-11 outlet to the incoming
water connection point using copper pipe (or order the exible hose kit offered by
the manufacturer).
If water hardness tests at 5 GPG or less, install the water supply line to the
dishmachine’s incoming water connection point using copper pipe (or order the
exible hose kit offered by the manufacturer). A water shut-off valve should be
installed to allow access for service.
The manufacturer recommends the installation of a water pressure regulator in the
incoming water line to ensure proper owrate at all times and offers these devices as
options. See the Plumbing Options page.
Do not confuse static pressure with ow pressure. Static pressure is the line pressure
in a “no ow” condition (all valves and services are closed). Flow pressure is the
pressure in the ll line when the ll valve is opened during the cycle.
The manufacturer also recommends the installation of a shock absorber in the
incoming water line and offers these devices as options. This prevents line hammer/
hydraulic shock—induced by the solenoid valve as it operates—from causing damage
to the equipment. See the Plumbing Options page.
The dishmachine's drain is a gravity-discharge drain. All piping from the 1 1/2” NPT
connection on the wash tank must be pitched (1/4” per foot) to the oor or sink drain.
All piping from the machine to the drain must be a minimum 1 1/2” NPT and must not
be reduced. There must also be an air-gap between the machine drain line and the
oor sink or drain. If a grease trap is required by code, it should have a ow capacity
of 5 GPM.
Take care not to confuse
static pressure with
ow pressure.
INSTRUCTIONS
INSTALLATION
