Jackson TempStar Series User Manual

07610-002-23-32-AC
8
OPERATING CAPACITY:
Normal Cycle
Racks per Hour 53
Dishes per Hour 1325
Glasses per Hour 1908
Medium Cycle
Racks per Hour 28
Dishes per Hour 700
Glasses per Hour 1008
Heavy Cycle
Racks per Hour 19
Dishes per Hour 475
Glasses per Hour 684
Extra-heavy Cycle
Racks per Hour 11
Dishes per Hour 275
Glasses per Hour 396
OPERATING CYCLES (SECONDS):
Wash Rinse Dwell Total
Ventless:
Wash Time 45
Rinse Time 15
Dwell Time 2
Condensate Removal 30
Total 92
Tank Capacity:
Rinse Tank (gallons/liters) 3.0/11.4
Wash Tank (gallons/liters) 8.0/30.3
MOTOR HP:
Wash Motor HP 2.0
WATER REQUIREMENTS:
TempStar HH & TempStar HH Ventless:
Wash Temperature (minimum) (°F/°C) 150/66
Rinse Temperature (minimum) (°F/°C) 180/83
Inlet Water Temperature:
12 kW Rinse Heater (°F/°C) 140/60
14 kW Rinse Heater (°F/°C) 110/44
14 kW Ventless (°F) 40-70
14 kW Ventless (°C) 4.4-21
Flow Pressure (PSI) 20±5
Water Line Size (NPT) 3/4"
Drain Line Size (NPT) 1 1/2"
TempStar HH-E:
Wash Temperature (minimum) (°F/°C) 155/68
Rinse Temperature (minimum) (°F/°C) 180/83
Inlet Water Temperature (°F/°C) 110/44
Flow Pressure (PSI) 10
Water Line Size (NPT) 1/2"
Drain Line Size (NPT) 1 1/2"
TempStar HH NB/Tempstar HH S:
Wash Temperature (minimum) (°F/°C) 150/66
Rinse Temperature (minimum) (°F/°C) 180/83
Inlet Water Temperature (°F/°C) 180/83
Flow Pressure (PSI) 20±5
Water Line Size (NPT) 3/4"
Drain Line Size (NPT) 1 1/2"
TempStar HH LT:
Wash Temperature (minimum) (°F/°C) 120/49
Rinse Temperature (minimum) (°F/°C) 120/49
Inlet Water Temperature (°F/°C) 120/49
Flow Pressure (PSI) 20±5
Water Line Size (NPT) 3/4"
Drain Line Size (NPT) 1 1/2"
STEAM REQUIREMENTS:
Coil Size 3/4"
Steam Flow Pressure (PSI) 10-30
Consumption @ 15 PSI (lbs/hr) 45
OPERATING PARAMETERS
SPECIFICATIONS
NOTICE
i
Always refer to the machine data plate for specic electrical and water requirements.
The material provided on this page is for reference only and is subject to change without notice.
HH-E 40 10 10 60
Normal 45 15 2 62
Medium 103 15 2 120
Heavy 163 15 2 180
Extra-Heavy 283 15 2 300

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
