Jackson TempStar Series User Manual

07610-002-23-32-AC
34
ITEM QTY DESCRIPTION PART NUMBER
34 1 Fuse Holder, 6-Pole (Not Shown) 05920-002-42-13
35 2 Screw, 6-32 x 3/8" with Tooth Washer (Not Shown) 05305-002-25-91
36
1 Decal, Dispenser Connection (Not Shown) 09905-003-34-09
1 Decal, Dispenser Connection (460 V Unit Only) (Not Shown) 09905-004-43-81
37 1 Timer, Universal 05945-003-75-23
38 4 Locknut, 10-32 (Not Shown) 05310-373-02-00
39 4 Screw 10-32 x 1" (Not Shown) 05305-002-19-42
40 1 Switch, Rotary Selector 05930-003-97-61
41 1 Switch, Operation 05930-301-53-00
42 1 Switch, Power 05930-011-49-55
43* 1 Overload, TK-ONY (460 V Unit Only) 05945-002-65-02
44* 1 Motor Contactor, SC-03Y (460 V Unit Only) 05945-002-65-00
45* 1 Din Rail, 2 3/4" (460 V Unit Only) 05700-001-84-65
*For a 460 V Unit, replace item 4 with items 43, 44 & 45.
TOP-MOUNT CONTROL BOX
PARTS

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
