Jackson TempStar Series User Manual

37
07610-002-23-32-AC
ITEM QTY DESCRIPTION PART NUMBER
25
1 Cover, Control Box Weldment 05700-002-06-51
Cover, Control Box Weldment (Not Shown) (LT Only) 05700-004-22-50
26 4 Bolt, 10-32 x 1/2" Slotted Truss 05305-173-04-00
27 1 Switch, Rotary Selector (Not on LT) 05930-003-97-61
28 1 Switch, Operation 05930-301-53-00
29
1 Decal, Control Box Cover 09905-003-97-39
1 Decal, Control Box Cover (Not Shown) (LT Only) 09905-004-22-33
30 1 Light, Red 05945-504-07-18
31 1 Light, Green Indicator 05945-504-08-18
32 1 Light, Amber 05945-504-06-18
33 1 Cover, Dielectric Control Panel (Not Shown) 05700-021-50-89
34 1 Contactor, 2-Pole, 220 V, 20 A (460 V Unit Only) 05945-002-65-00
35 1 Overload (460 V Unit Only) 05945-002-65-01
36 1 Switch, Power 05930-011-49-55
SIDE-MOUNT CONTROL BOX
PARTS

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
