Jackson TempStar Series User Manual

41
07610-002-23-32-AC
ITEM QTY DESCRIPTION PART NUMBER
16 8 Nut, 3/8-16 Hex 05310-276-01-00
17
2 Door, Upper, Left and Right Assemblies (Not Shown) 05700-002-01-30
2 Door, Upper, Left and Right Weldment 05700-002-29-59
18 4 Glide, Upper Door 05700-002-00-83
19
1 Door, Lower, Right Assembly (Not Shown) 05700-002-01-33
1 Door, Lower, Right 05700-004-14-17
20 2 Glide, Lower Door 05700-002-23-64
21 1 Bracket, Magnet Mounting See "Hood Assembly" page.
22 1 Magnetic Door Switch See "Hood Assembly" page.
23 12 Screw, 1/4-20 x 5/8" 05305-274-24-00
24 12 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
25 2 Screw, 1/4-20 x 1/2" Hex 05305-274-02-00
26 2 Spacer, PB Bolt 05700-000-29-40
27 2 Bracket, Door Connector 05700-004-14-24
28 1 Handle, Front Door Weldment 05700-004-14-30
29
1 Door, Lower, Front Assembly (Not Shown) 05700-004-14-21
1 Door, Lower, Front 05700-004-14-22
30 2 Glide, Upper Door 05700-002-23-64
31
1 Door, Upper Front Assembly (Not Shown) 05700-002-24-92
1 Door, Upper, Front Weldment 05700-002-29-57
32 2 Glide, Upper Door 05700-002-00-83
33
1 Door, Lower, Left Assembly (Not Shown) 05700-002-01-32
1 Door, Lower, Left Assembly (Door Lock) (Not Shown) 05700-004-24-22
1 Door, Lower, Left 05700-004-14-20
1 Door, Lower, Left (Door Lock) (Not Shown) 05700-004-24-23
1 Door Interlock Bracket (Not Shown) 05700-004-23-17
34 2 Glide, Lower Door 05700-002-23-64
35 6 Door Stop Weldment 05700-002-29-60
36 1 Door Stop Kit 06401-003-08-69
37 2 Cantilever Arm Support Bracket (Not Shown) 09515-003-15-64
38 6 Wear Button (Not Shown) 05700-011-88-01
CANTILEVER ARM/DOOR ASSEMBLY
PARTS

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
