Jackson TempStar Series User Manual

47
07610-002-23-32-AC
ITEM QTY DESCRIPTION PART NUMBER
12 1 Strainer Weldment 05700-003-07-76
13 1 Wash Overow Weldment 05700-001-25-69
13a 1 Support, Ball Stop Lift 05700-002-91-55
13b 1 Ball Stop Lift 05700-003-07-50
13c 1 Shim, Overow Support 05700-002-96-48
14 1 Overow Support Bracket 05700-001-27-55
15 1 O-ring 05330-400-05-00
16 2 Clamp, Hose 1 5/16” to 2 1/4” 04730-719-01-37
17 1 Discharge Hose 05700-011-88-24
18 1 Nipple 05700-021-34-84
19 Item intentionally left blank. N/A
20 1 Clamp, Hose 5 5/8" to 6" 04730-011-34-90
21 1 Connector, 1/2” 05975-111-01-00
22 4 Nut, 3/8-16 Hex 05310-276-01-00
23 4 Lockwasher, 3/8” 05311-276-01-00
24 1 Fitting, 1/4" Imperial Brass 05310-924-02-05
25 1 Probe, High Water 06680-200-02-68
26 1 Thermostat, Regulating 05930-510-02-79
1
Kit, Wash Thermostat Replacement
(Thermostat, brass tting, two jumper wires, and instructions)
06401-003-18-67
27 1 Cover, Wash Heater 05700-031-47-57
28 1 Decal, Warning-Disconnect Power 09905-004-08-16
29 2 Locknut, 10-24 with Nylon Insert 05310-373-01-00
30 3 Locknut, 6-32 with Nylon Insert 05310-373-03-00
31 1 Probe, Thermistor 4” 06685-004-17-26
32 1 Thermostat Mounting Bracket 05700-004-22-17
33 1 Thermostat, Elan Electric Dual 06685-004-17-27
34 1 Harness, 5-Connector 05700-004-23-78
35 1 Harness, 4-Connector 05700-004-23-79
36 1 Harness, 2-Connector 05700-004-23-80
37 1 Steam Coil See "Steam Coil Assembly" page.
STEAM TUB ASSEMBLY
PARTS

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
