51
07610-002-23-32-AC
ITEM QTY DESCRIPTION PART NUMBER
1 1 Y-strainer, 3/4” NPT Brass 04730-717-02-06
2 2 Nipple, 3/4" x 1 3/8" Closed Brass 04730-207-34-00
3 1 Bracket, Incoming Plumbing Support 05700-021-34-02
4 1 Tee, 3/4" x 3/4" x 1/4" Brass 06685-111-88-34
5 1 Valve, Ball Test Cock, Bronze 04810-011-72-67
6 1 Gauge, Pressure 1/4" BTM Connect 06685-111-88-34
7 1 Solenoid Valve, 3/4", 220 V 04810-100-03-18
8 1 Nipple, 3/4" x 2" NPT Brass 04730-207-46-00
9 1 Elbow, 3/4" Street Brass, 90-Degree 04730-206-04-34
10 2 Union, 3/4" Brass with O-ring 05700-002-63-79
11 2 Adapter, 3/4" Female 04730-401-11-01
12 1 Tube, Copper 3/4” x 48” 05700-011-87-89
13 2 Elbow, 3/4" 04730-406-16-01
14 2 Adapter, 3/4" 04730-401-10-01
15 1 Tube, Copper 1/2” x 3.25” 05700-002-25-06
INLET PLUMBING
PARTS
When servicing plumbing components, take care not to damage the threads of each individual item. Damaged threads
can cause leaks and loss of pressure, which could adversely affect the performance of the dishmachine. It is strongly
recommended that teon thread tape, used in conservative amounts, be applied to threads when joining components
together. It is not advised to use thread-sealing compounds, sometimes referred to as “pipe dope." Compounds can be
ejected from the threads during the tightening process and become lodged in key components, rendering them useless.
