55
07610-002-23-32-AC
INLET PLUMBING - HH-E
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Y-strainer, 1/2" Brass 04730-217-01-10
2 2 Nipple, 1/2" Close Brass 04730-207-15-00
3 1 Tee, 1/2" x 1/2" x 1/4" 04730-002-22-56
4 1 Gauge, Pressure 06685-111-88-34
5 2 Nipple, 1/2" x 4" Brass 04730-207-04-00
6 1 Bracket, Incoming Plumbing 05700-004-48-11
7 1 Solenoid Valve, 1/2", 208 V 04810-003-71-56
8 1 Union, 1/2" x 1/2" Brass 04730-003-62-44
9 1 Elbow, 90-degree, 1/2" Street Brass 04730-206-08-00
10 1 Nipple, 1/2" x 2" Brass 04730-207-19-00
11 1 Casting, 1/2" Flanged Coupling 05700-004-47-97
12 1 Hose Assembly, 1/2" x 48" Blue 05700-004-48-23
13 1 Bushing, 3/4" to 1/2" Brass 04730-002-56-27
14 1 Elbow, 90-degree, 1/2" Brass 04730-011-42-96
When servicing plumbing components, take care not to damage the threads of each individual item. Damaged threads
can cause leaks and loss of pressure, which could adversely affect the performance of the dishmachine. It is strongly
recommended that teon thread tape, used in conservative amounts, be applied to threads when joining components
together. It is not advised to use thread-sealing compounds, sometimes referred to as “pipe dope." Compounds can be
ejected from the threads during the tightening process and become lodged in key components, rendering them useless.
