Jackson TempStar Series User Manual

69
07610-002-23-32-AC
ITEM QTY DESCRIPTION PART NUMBER
1 1 Upper Manifold 05700-031-34-82
2 4 Nut, 3/8-16 Hex 05310-276-01-00
3 4 Lockwasher, 3/8" 05311-276-01-00
4 2 Bolt, Hex 3/8-16 x 7/8" 05306-011-36-95
5 2 O-ring 05330-111-35-15
6 1 Positioning Bracket, Manifold Tube 05700-011-34-63
7 1 Tube, Wash Manifold 05700-031-92-58
8 2 Gasket, Manifold 05700-111-35-03
9 1 Wash Arm Assembly 05700-004-13-13
10 1 Bearing Assembly 05700-021-35-97
11 2 Clip, Retaining, Rinse Head Bushing 05340-112-01-11
12 4 Washer 05330-011-42-10
13 2 Bushing, Rinse Head 05700-021-33-84
14
2
Complete Rinse Arm Assembly
Complete Rinse Arm Assembly, HH-E Only
05700-002-58-09
05700-004-47-74
2
Rinse Arm
Rinse Arm, HH-E Only
05700-031-49-58
05700-004-47-56
15 4 Plug 04730-111-60-41
16 2 Bearing 03120-004-12-13
17 1 Lower Wash Manifold Weldment 05700-002-21-70
18 5 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
19 1 Rinse Manifold Weldment 05700-002-01-19
20 2 Bolt, Hex 3/8-16 x 1 1/4" 05305-276-10-00
21 1 Wash Arm, Double Assembly 05700-003-94-00
1 Wash Arm, Double Assembly, 460 V (Not Shown) 05700-002-46-86
1 Wash Arm Assembly, 460 V (Not Shown) 05700-021-63-81
1 Wash Arm Weldment, 460 V (Not Shown) 05700-021-63-42
1 Bearing Assembly, 460 V (Not Shown) 05700-021-63-80
Rinse Arm Bearing Kit
(Includes items 11, 12, and 16)
06401-004-33-51
WASH & RINSE ASSEMBLIES
PARTS
See Maintenance section for replacement instructions.

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
