Jackson TEMPSTAR - Unit and Table Dimensions

07610-003-61-42-T
Model Designation: TEMPSTAR
PERFORMANCE/CAPABILITIES
Operating Capacity:
High Temperature
Racks per Hour 58
Dishes per Hour 1450
Glasses per Hour 1450
Low Temperature
Racks per Hour 50
Dishes per Hour 1250
Glasses per Hour 1250
Operating Cycle (SECONDS):
Minimum (other cycle times are available)
High Temperature
Wash Time 40
Rinse Time 13
Dwell Time 4
Total Cycle Time 57
High Temperature Ventless
Wash Time 40
Rinse Time 13
Dwell Time 4
Condensate Removal 30
Total Cycle Time 87
Low Temperature
Wash Time 45
Rinse Time 11
Dwell Time 10
Total Cycle Time 66
Tank Capacity (Gallons):
Wash Tank 8.0
Rinse Tank (TEMPSTAR) 3.0
Tank Capacity (Liters):
Wash Tank 30.3
Rinse Tank (TEMPSTAR) 11.4
Steam Requirements:
Coil Size 3/4"
Steam Flow Pressure (P.S.I) 10-20
Consumption @ 15 P.S.I. ( Lbs/Hr) 45
OPERATING CAPACITIES
SPECIFICATIONS
Electrical Loads (as applicable):
Wash Motor HP 3/4
Wash Heater KW 4
Rinse Heater KW 4
WATER REQUIREMENTS
TEMPSTAR & VENTLESS:
Wash Temperature (Minimum)(°F) 150
Wash Temperature (Minimum)(°C) 66
Rinse Temperature (Minimum)(°F) 180
Rinse Temperature (Minimum)(°C) 83
Inlet Water Temperature:
12KW Rinse Heater (°F) 140
12KW Rinse Heater (°C) 60
14KW Rinse Heater (°F) 110
14KW Rinse Heater (°C) 44
Ventless (°F) 40-70
Ventless (°C) 4.4-21
Flow Pressure (PSI) 10
Water Line Size (NPT) (Vented) 1/2”
Water Linse Sze (Ventless) 3/4"
Drain Line Size (NPT) 1 1/2”
TEMPSTAR LT:
Wash Temperature (Minimum)(°F) 130
Wash Temperature (Minimum)(°C) 55
Rinse Temperature (Minimum)(°F) 130
Rinse Temperature (Minimum)(°C) 55
Inlet Water Temperature (°F) 130
Inlet Water Temperature (°C) 55
Flow Pressure (PSI) 10
Water Line Size (NPT) 1/2”
Drain Line Size (NPT) 1 1/2”
Minimum Chlorine Required (PPM) 50
TEMPSTAR NB/ TEMPSTAR S:
Wash Temperature (Minimum)(°F) 150
Wash Temperature (Minimum)(°C) 66
Rinse Temperature (Minimum)(°F) 180
Rinse Temperature (Minimum)(°C) 83
Inlet Water Temperature (°F) 180
Inlet Water Temperature (°C) 83
Flow Pressure (PSI) 10
Water Line Size (NPT) 1/2”
Drain Line Size (NPT) 1 1/2”
NOTE: Always refer to the machine data plate for specifi c electrical and water requirements.
The material provided on this page is for reference only and is subject to change without notice.
5
