Jackson TEMPSTAR - Incoming Steam Plumbing Assembly

41
07610-003-61-42-T
INCOMING STEAM PLUMBING ASSEMBLIES
PARTS
ITEM QTY DESCRIPTION PART NUMBER
Complete Assembly 05700-002-01-55
1 1 Union, 3/4’’ NPT, Black Iron 04730-912-01-00
2 1 Bushing, Reducing, 3/4’’ to 1/2’’ 04730-911-02-34
3 2 Elbow, 3/4” 90° Street 04730-011-87-37
4 1 Nipple, Close, 3/4’’ NPT, Black Iron 04730-907-01-00
5 1 Steam Trap, 3/4” NPT F&T 06680-500-02-77
1
2
3
4
5
