63
07610-003-61-42-T
PARTS
GO*BOX COMPONENTS
A GO*BOX is a kit of the most needed parts for a particular model or model family to successfully effect a repair in the rst
call 90% or more of the time.
The following components may be ordered together using the following Mfg. No.: 06401-003-62-04
ITEM QTY DESCRIPTION PART NUMBER
1 1 Contactor, Rinse/Wash Heater 05945-109-01-69
2 1 Contactor, Wash Motor 05945-002-74-20
3 1 Gauge, Pressure, 0-100 PSI 06685-111-88-34
4 1 Thermometer, 96" Capillary 06685-111-68-49
5 1 Thermometer, 48" Capillary 06685-111-68-48
6 1 Thermostat, Rinse Operating 06401-140-00-33
7 1 Thermostat, Wash Operating 06401-140-00-32
8 1 Thermostat, Hi-Limit 05930-011-49-43
9 1 Liquid Level Control 06680-200-08-21
10 1 Probe, water level sensing 06680-200-02-68
11 1 Magnet,Door 05930-111-51-68
12 6 Glide, Door Edge 05700-111-33-59
13 2 O-Ring Wash Manifold 05330-111-35-15
14 1 Relay,Control 240V 50/60Hz 05945-111-47-51
15 1 Seal, Mechanical Pump (S/S Pumps) 05330-002-34-22
16 1 O-Ring, Wash Pump Gasket 05330-002-81-83
17 1 Switch, Door, Magnetic Reed 05930-111-51-69
18 2 Snap Ring, Retaining, Rinse Arm 05340-112-01-11
19 1 Bearing Assembly, Wash Arm 05700-021-35-97
20 1 Switch, Power Push Button 05930-002-29-13
21 1 Timer, Universal 05945-003-33-09
22 4 Washer, Rinse Arm Nylatron 05330-011-42-10
23 1 Vacuum Breaker 1/2" Brass 04820-003-06-13
24 1 Valve, Solenoid, 1/2", 208-220V 04810-100-09-18
* 1 Pump & Motor Assembly, S/S 06105-002-69-78
Special pricing available when purchased with above GO*BOX. Call for details.
