Jackson TEMPSTAR - Hood Assembly (Bolted Single Support Design)

27
07610-003-61-42-T
HOOD ASSEMBLY
PARTS
2
1
3
4
ITEM QTY DESCRIPTION PART NUMBER
1 1 Hood Weldment (Tempstar/Tempstar LT/Tempstar NB) 05700-002-29-79
2 2 Hood Support 05700-002-78-99
3 6 Bolt, 1/4”-20 x 1/2” Lon 05305-274-21-00
4 6 Washer, Flat, SS, 1/4”-20 ID 05311-174-01-00
5 4 Spacer, Sleeve Hood 05700-003-55-15
6 6 Locknut, 1/4”-20 with Nylon Insert (Not Shown) 05310-374-01-00
5
