43
07610-003-61-42-T
WASH MOTORS
PARTS
MODEL VOLTS HZ PHASE WASH MOTOR ASSEMBLY
Tempstar/Tempstar NB 208 50 1 06105-002-19-87
Tempstar/Tempstar NB 208 50 3 06105-002-19-87
Tempstar/Tempstar NB 208 60 1 06105-002-69-78
Tempstar/Tempstar NB 208 60 3 06105-002-69-78
Tempstar/Tempstar NB 230 50 1 06105-002-19-87
Tempstar/Tempstar NB 230 50 3 06105-002-19-87
Tempstar/Tempstar NB 230 60 1 06105-002-69-78
Tempstar/Tempstar NB 230 60 3 06105-002-69-78
Tempstar/Tempstar NB 380 50 3 06105-002-41-24
Tempstar/Tempstar NB 415 50 3 06105-002-41-24
Tempstar/Tempstar NB 440 50 3 06105-002-41-24
Tempstar/Tempstar NB 460 60 3 06105-121-64-21
The Tempstar models covered in this manual come supplied with various wash motor assemblies (a wash motor assembly
includes the wash motor and the pump end), depending on the characteristics of the machine. To ensure that you order
the correct wash motor assembly for the model you are servicing, please refer to the following table:
MODEL VOLTS HZ PHASE WASH MOTOR ASSEMBLY
Tempstar LT 208 50 1 06105-002-19-87
Tempstar LT 208 50 3 06105-002-19-87
Tempstar LT 208 60 1 06105-002-69-78
Tempstar LT 208 60 3 06105-002-69-78
Tempstar LT 230 50 1 06105-002-19-87
Tempstar LT 230 50 3 06105-002-19-87
Tempstar LT 230 60 1 06105-002-69-78
Tempstar LT 230 60 3 06105-002-69-78
Tempstar LT 380 50 3 06105-002-41-24
Tempstar LT 415 50 3 06105-002-41-24
Tempstar LT 440 50 3 06105-002-41-24
Tempstar LT 460 60 3 06105-121-64-21
Important note: When servicing a wash motor, it is important to refer to the wiring schematic found on the motor, to ensure
that the motor is wired correctly. Different manufacturers of motors may not use the same wire color codes and therefore,
your new motor, which may have been built by someone different than who built your original motor, may not connect using
the same wires. Always refer to the wiring diagrams on the motor you are installing. If the motor you are installing has had the
schematic removed, contact Jackson WWS,INC. immediately for technical support.
