Jackson TEMPSTAR - Frame Assembly

07610-003-61-42-T
37
FRAME ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 4 Bolt, 1/4”-20 x 1/2” 05305-274-02-00
2 4 Locknut, 1/4”-20 S/S Hex with Nylon Insert 05310-374-02-00
3 1 Front Panel 05700-002-36-65
4 1 Frame Weldment 05700-031-48-01
5 4 Bullet Foot 05340-108-01-03
6 4 Flanged Bullet Foot 05340-002-34-86
2
1
3
4
5
6
