Jackson TEMPSTAR - Coil Assembly

40
07610-003-61-42-T
COIL ASSEMBLY
ITEM QTY DESCRIPTION PART NUMBER
Complete Steam Coil Assembly 05700-002-08-62
1 1 Steam Coil Weldment 05700-021-41-38
2 1 Stand C, Steam Coil Support 05700-002-08-52
3 1 Stand D, Steam Coil Support 05700-002-08-53
4 4 Gasket, Steam Coil 05700-001-17-86
5 2 Washer, Steam Coil 05700-001-17-87
6 2 Adapter, Steam Coil Nut 05310-011-17-85
7 1 Stand A, Steam Coil Support 05700-002-08-50
8 1 Stand B, Steam Coil Support 05700-002-08-51
1
3
4
5
6
7
8
2
PARTS
