7
07610-003-61-42-T
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
VOLTS PHASE HZ
RINSE HEATER
RATINGS
TOTAL
AMPS
TYPICAL
ELECTRICAL CIRCUIT
208 1 50 N/A 28 A 35 AMP
230 1 50 N/A 30 A 100 AMP
TEMPSTAR LT/TEMPSTAR NB Electrical Characteristics:
208 3 50 N/A 20A 25 AMP
230 3 50 N/A 21 A 30 AMP
380 3 50 N/A 10 A 15 AMP
415 3 50 N/A 10 A 15 AMP
440 3 50 N/A 8 A 15 AMP
208 1 60 N/A 26 A 35 AMP
230 1 60 N/A 28 A 35 AMP
208 1 60 N/A 26 A 35 AMP
230 1 60 N/A 28 A 35 AMP
208 3 60 N/A 18 A 25 AMP
230 3 60 N/A 28 A 35 AMP
460 3 60 N/A 8 A 15 AMP
TEMPSTAR S Electrical Characteristics:
VOLTS PHASE HZ
RINSE HEATER
RATINGS
TOTAL
AMPS
TYPICAL
ELECTRICAL CIRCUIT
208 1 60 N/A 6 A 15 AMP
230 1 60 N/A 6 A 15 AMP
208 3 60 N/A 6 A 15 AMP
230 3 60 N/A 6 A 15 AMP
