TUB ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Tub Weldment 05700-002-12-59
2 1 Rack Assembly 05700-002-01-00
3 2 Bulk Head Plug 04730-609-05-00
4 1 See Page Entitled “Wash Motors” N/A
5 1 Gasket 05700-111-35-03
6 1 O-ring 05330-400-05-00
7 4 Bolt, Hex 3/8”-16 x 1 1/4" Long 05305-276-10-00
8 1 Lower Wash Manifold Weldment 05700-031-46-00
9 1 Suction Strain Weldment 05700-001-22-23
10 1 Suction Strain Bracket 05700-001-22-24
11 8 Locknut, 1/4"-20 with Nylon Insert 05310-374-02-00
12 1 Strainer Weldment 05700-003-07-76
13 1 Wash Overfl ow Weldment 05700-001-25-69
* 1 Support, Ball Stop Lift 05700-002-91-55
* 1 Ball Stop Lift 05700-002-91-54
* 1 Shim, Overfl ow Support 05700-002-96-48
14 1 Overfl ow Support Bracket 05700-001-27-55
15 1 O-Ring 05330-400-05-00
16 2 Clamp, Hose 1 5/16” to 2 1/4” 04730-719-01-37
17 1 Discharge Hose 05700-011-88-24
18 1 Nipple 05700-021-34-84
19 1 Pump Support Bracket Assembly 05700-002-00-46
20 1 Clamp, Hose 5 5/8" to 6" 04730-011-34-90
21 1 Connector, 1/2” 90B 05975-111-01-00
22 4 Nut, 3/8"-16 S/S Hex 05310-276-01-00
23 4 Lockwasher 3/8” 05311-276-01-00
24 1 See Page Entitled “Wash Heaters/Rinse Heaters” N/A
See page 43 to order phase conversion kits for heater.
25 5 Probe, High Water 06680-200-02-68
26 1 Locknut, 6-32 with Nylon Insert 05310-373-03-00
27 Lockwasher, 5/16", S/S, Split 05311-275-01-00
To Next Page
