Jackson TEMPSTAR - Page 42

35
07610-003-61-42-T
STEAM TUB ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
11
Tub Weldment
05700-002-12-59
21
Rack Assembly
05700-002-01-00
32
Bulk Head Plug
04730-609-05-00
41
See Page Entitled “Wash Motors”
N/A
51
Gasket
05700-111-35-03
61
O-ring
05330-400-05-00
74
Bolt, Hex 3/8”-16 x 1 1/4" Long
05305-276-10-00
81
Lower Wash Manifold Weldment
05700-031-46-00
91
Suction Strain Weldment
05700-001-22-23
10 1
Suction Strain Bracket
05700-001-22-24
11 8
Locknut, 1/4"-20 with Nylon Insert
05310-374-02-00
12 1
Strainer Weldment
05700-003-07-76
13 1
Wash Overfl ow Weldment
05700-001-25-69
*1
Support, Ball Stop Lift
05700-002-91-55
*1
Ball Stop Lift
05700-002-91-54
*1
Shim, Overfl ow Support
05700-002-96-48
14 1
Overfl ow Support Bracket
05700-001-27-55
15 1
O-Ring
05330-400-05-00
16 2
Clamp, Hose 1 5/16” to 2 1/4”
04730-719-01-37
17 1
Discharge Hose
05700-011-88-24
18 1
Nipple
05700-021-34-84
19 1
Pump Support Bracket Assembly
05700-002-00-46
20 1
Clamp, Hose 5 5/8" to 6"
04730-011-34-90
21 1
Connector, 1/2” 90B
05975-111-01-00
22 4
Nut, 3/8"-16 S/S Hex
05310-276-01-00
23 4
Lockwasher 3/8”
05311-276-01-00
24 1
Fitting, 1/4" Imperial Brass
N/A
