51
07610-003-61-42-T
PARTS
INCOMING/OUTLET PLUMBING ASSEMBLY
ITEM QTY DESCRIPTION PART NUMBER
1 1 Water Pressure Regulator, 1/2" NPT 05700-100-04-07
2 1 Valve, Ball, 1/4" NPT 04810-011-72-67
3 1 Gauge, Pressure, 0-100 PSI 06685-111-88-34
4 1 Tee, Brass, 1/2" NPT x 1/2" x 1/4" 04730-411-25-01
5 1 Valve, Solenoid, 1/2" NPT 04730-100-09-18
6 2 Bracket, Booster Plumbing 1/2” (Not Shown) 05700-003-60-90
7 2 Bushing, HEX 3/4 MNPT-1/2 FNPT Brass 04730-002-56-27
8 3 Union, 1/2” 04730-406-01-01
9 2 Adapter, 1/2” MNPT x CU Male 04730-011-59-53
10 1 Tube, Copper See Chart pg. 46
11 3 Elbow, 1/2" CU x CU, 90B 04730-406-01-01
12 6 Adapter, 1/2” 04730-401-03-01
13 1 Tube, Copper See Chart pg. 46
14 1 Vacuum Breaker, 1/2" NPT 04820-003-06-13
15 1 Tube, Copper See Chart pg. 46
16 1 Elbow, 1/2" NPT, 90B, Brass 04730-011-42-96
17 3 Tube, Copper See Chart pg. 46
18 1 Tube, Copper See Chart pg. 46
19 2 Tube, Copper See Chart pg. 46
When servicing plumbing components, take care not to damage the threads of each individual item. Damaged threads can
cause leaks and loss of pressure, which could adversely effect the performance of the Tempstar dishmachine. It is strongly
recommended that tefl on thread tape, used in conservative amounts, be applied to threads when joining components
together. It is not advised to use thread sealing compounds, sometimes referred to as “pipe dope”. Compounds can be
ejected from the threads during the tightening process and become lodged in key components, thereby rendering them
useless. Some of the components include the solenoid valve and the pressure gauge isolation ball valve.
