65
07610-003-61-42-T
PARTS
DRAIN QUENCH ASSEMBLY
(Continued)
ITEM QTY DESCRIPTION PART NUMBER
1 1 Wash Heater Cover 05700-004-07-92
2 1 Liquid Tight Fitting (Large) 05975-011-65-51
3 1 Conduit Fitting, 45°-1/2" 05975-011-45-23
4 2 Lock Nut, 6-32 Hex 05310-373-03-00
5 1 Thermostat 05930-003-13-65
6 1 Conduit Fitting, 90°-1/2" 05975-011-45-14
7 1 Liquid Tight Fitting (Small) 05975-011-49-03
1
2
3
4
5
6
7
