CONTROLS 4
en-28
4.2.23.5 THE ENGINE WILL NOT START____________________________________________
When the ignition key is turned to the start position this screen is shown. If any of
the following flash.
• The parking brake is not applied.
• The mow switch is not in the OFF position.
• The foot pedal is not in the Neutral position.
• The operator is not in the seat.
Note. The red LED’s either side of the display will also flash.
The engine will not start until all the items in the list are correct.
SET-UP
4.2.23.6 MANUAL REVERSE FAN CYCLE SELECT ___________________________________
To start a manual reverse fan cycle, press the button below the icon.
4.2.23.7 BRIGHTNESS ADJUST ___________________________________________________
Use the buttons below the + and - icons on the screen to increase and decrease
the brightness.
