75
> Change from previous revision
R-311
Item Part No. Qty. Description Serial Numbers/Notes
1
503612 1 Hydraulic Oil Tank Includes Decals
2 365919 1 • Decal, Oil Fill Caution
3 352487 1 • Decal, Hydraulic Fluid
4 367551 1 Switch, Hydraulic Oil Temperature REFERENCE SW13, See 60.1
H 5 163915 1 Breather, Tank
Important note located below
H 6 557680 1 • Screen
H 7 557681 2 • Gasket, Rubber
H 8 402120 6 Screw, #10-24 x 5/8” Slotted
9 338941 1 Foam, Tank
10 558012 AR Pad, Tank (Cut to Fit) 10 Foot Roll
11 400268 2 Screw, 3/8-16 x 1-3/4” Hex Head
12 453011 2 Flat WAsher, 3/8
13 3001409 2 Strap, Oil Tank
14 444762 2 Locknut, 3/8-16 Center
15 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
16 446142 2 Lockwasher, 3/8 Heavy
17 443110 2 Nut, 3/8-16 Hex
18 365959 1 Strainer, 100 Mesh Screen
2812075 1 • O-Ring
19 69051-04 1 Plug, Pipe
H
IMPORTANT: Discard the six #10-32 x 1/2” self threading screws included with Tank Breather Assembly. Using self threading
screws will cause damage to hydraulic tank. Use #10-24 x 5/8” Slotted Head screws (Item 8) to secure breather to tank.
