© Copyright 2009, Jacobsen, A Textron Company. “All rights
reserved, including the right to reproduce this material or portions
thereof in any form.”
This manual contains adjustment, maintenance, troubleshooting
instructions, and parts list for your new Jacobsen machine. This
manual should be stored with the equipment for reference during
operation.
Before you operate your machine, you and each operator you employ
should read the manual carefully in its entirety. By following the
safety, operating, and maintenance instructions, you will prolong the
life of your equipment and maintain its maximum efficiency.
If additional information is needed, contact your Jacobsen Dealer.
The serial plate is located on the right frame rail. Jacobsen
recommends you record these numbers below for easy reference.
CHARLOTTE, NC MADE IN U.S.A.
®
2
Proposition 65 Warning
This product contains or emits chemicals known
to State of California to cause cancer and birth
defects or other reproductive harm.
FOREWORD
Suggested Stocking Guide
To Keep your Equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more commonly used maintenance
items. We have included part numbers for additional support materials and training aids.
To order any of the following material:
1. Write your full name and complete address on your order form.
2. Explain where and how to make shipment:
q UPS q Regular Mail
q Overnight q 2nd Day
3. Order by the quantity desired, the part number, and the descrip-
tion of the part.
4. Send or bring the order to your authorized Jacobsen Dealer.
Litho In U.S.A. 2-2009
Service Parts
Service Support Material
Qty. Part No. Description Qty. Part No. Description
4113986 Engine Oil Filter 555771 Hydraulic Return Oil Filter
549633 Engine Air Filter 2811255 Hydraulic Charge Oil FIlter
557619 Engine Fuel Filter
Qty. Part No. Description
4192120 Safety & Operation Manual
4192121 Parts & Maintenance
4192126 Kubota Engine Parts Manual
Qty. Description
Service Manual
