SPECIFICATIONS 2
7
2.4 CUTTING UNITS ___________________________________________________________________________
Type.........................................Three Fully Floating Decks
Width:
Front Deck........................ 64 in. (1625 mm)
Wing Decks...................... 42 in. (1067 mm)
Cutting Width:
Front and both Wings.......134 in. (3403 mm)
Front and one wing...........99 in. (2514 mm)
Front only .........................64 in. (1625 mm)
Drive ........................................Hydraulic Motors
Cutting Height..........................1.00 - 5.5 in. (25 - 140 mm)
2.5 WEIGHTS AND DIMENSIONS ________________________________________________________________
Dimensions: Inches (mm)
Length.............................................................................144 (3657)
Height (ROPS)..................................................................84 (2134)
Height (ROPS with Canopy).............................................92 (2337)
Height (ROPS Folded)...................................................63.5 (1613)
Wheel Base ...................................................................67.8 (1722)
Width - Transport Position.............................................93.5 (2375)
Width - Mowing Position.................................................139 (3530)
Ground Clearance..............................................................8 (203)
Turning Radius.................................................................33 (838)
Weights: Lbs. (kg)
Fuel tank filled and cutting units installed. Less
Operator................................... .........................................3970(1801)
2.6 ACCESSORIES AND SUPPORT LITERATURE __________________________________________________
Contact your area Jacobsen Dealer for a complete listing of accessories and attachments.
Accessories
Air Blow Gun................................................................................JAC5098
Orange Touch-up Paint (12 oz. spray)...........................................554598
Mulcher Kit........................................................................................69123
High Lift Blade Kit...........................................................................970198
Care Free Tire Kit.........................................................................2811453
Canopy / Sunshade..........................................................................68095
Light Kit.........................................................................................4194160
Blade Balancer............................................................................JAC5016
Cab/Cab Accessories............................................................................... l
Brush/Sweeper........................................................................................ u
Snow Blower............................................................................................ s
l Contact: Jodale Perry Corporation
Box 990, 300 Route 100
Morden, Manitoba, Canada R6M 1A8
Phone: (204) 822-9100
Fax: (204) 822-9111
u Contact: Loftness Specialized Equipment, Inc.
South Highway 4
Hector, MN 55342
Phone 800 . 848 . 7624
ATTN Doug Haley
Support Literature
Safety & Operation Manual...........................................................4192120
Parts & Maintenance Manual........................................................4192121
Diesel Engine Parts Catalog.........................................................4192126
s Contact: M-B Companies, Inc.
1200 S. Park Street, Box 148
Chilton, WI 53014
Phone: (888) 558-5801
Fax: (414) 849-2109
CAUTION
Use of other than Jacobsen authorized parts and accessories may cause personal injury or damage to the equipment and will void the
warranty
